近日，国外一些网站刊登了丽台WinFast NF4UK8AA-8EKRS，这是一款基于nVidia nForce4 Ultra芯片组的主板产品。丽台与nVidia的关系密切，其NV系列显卡深受国内用户喜爱，相信这款来自丽台的NF4U主板同样不会令您失望。
|
WinFast NF4UK8AA-8EKRS | |
|
CPU |
AMD Athlon 64 FX / Athlon 64 for Socket 939 |
|
Chipset |
NVIDIA nForce4 Ultra |
|
Hypertransport bus |
1 GHz |
|
Clock generator frequency, MHz |
200-400 (with 1MHz increment) |
|
Overclocking friendly functions |
Adjustable Vcore, Vmem, Vchipset and HyperTransport bus voltage. |
|
Memory |
4 DDR DIMM slots for dual-channel DDR400 SDRAM |
|
PCI Express slots |
1 x PCI Express x16 |
|
PCI expansion slots |
4 |
|
USB 2.0 ports |
8 (4 on the back panel) |
|
IEEE1394 ports |
2 (1 on the back panel, implemented via the Agere FW3226-100 controller) |
|
ATA-100/133 |
2 ATA-133 channels |
|
Serial ATA |
4 Serial ATA-300 channels (with RAID support) |
|
IDE RAID support |
RAID 0, 1, 0+1 |
|
Integrated sound |
8-channel AC97 codec: Realtek ALC850 |
|
Integrated LAN |
Vitesse VSC8201RX Gigabit Ethernet PHY |
|
Additional features |
None |
|
BIOS |
Phoenix-AwardBIOS v6.00PG |
|
Form-factor |
ATX, 305x245mm |
